Kingspec 2.5 inch PATA SSD 64GB ssd ide Solid State Drive 60GB Internal Hard Drives ssd disk for ibm for hp for dell for sony

Model

PATA 2.5

General

Form factor

2.5

Interface

PATA

Performance

Capacity

8GB | 16GB | 32GB | 64GB | 128GB

Sustained Read

90MB/S | 100MB/S | 105MB/S | 108MB/S | 107MB/S

Sustained Write

26MB/S | 30MB/S | 60MB/S | 30MB/S | 59MB/S | 60MB/S

Random IOPS

4KB Random Read IOPS

4KB Random Write IOPS

Average Access time

0.3ms

Storage Media

NAND Flash

MLC-NAND Flash

Power Consumption

input Voltage

5V+/_5%

Idle

0.5W

Active

2.0W

Reliability& Endurance

Write endurance

8years 100GBytes write and erase per day at 32GB

Read endurance

unlimited

Wear-Leveling Algorithm

Dynamic and static wear-leveling

Data Retention

10years at 25

MTBF

1,000,000hours

ECC

Supports BCH ECC 8bits or 15bits in 512 bytes

Bad Block Management

Auto Bad Block Management in system

Environment

Operating Temperature

0~70

Non-operating Temperature

-40~85

Shock

2,000G(0.3ms half sine wave)

Vibration

20G(40-2000HZ)

Ambient Humidity

5-95%

Warranty

2years

Available unit

Available

NO EOL

Testing Platform

CPU:Athlon 64×2 5200+ 2.7GHz,SDRAM:DDR2 800(PC6400) 2048 MB×1PCS, Mainboard: RS780 (ATI Radeon HD 3200 Graphics)System:Professional SP2

Testing Software

HDBench3.4.0.3, IOMeter 2006.07.27

Physical Dimensions & Weight

Height(mm)

9.5+/_0.25

Width(mm)

69.8+/_0.25

Length(mm)

100+/_0.25

Weight(g)

75±5
